10' TuffBase

Foundation System

  • Key Engineering Features
    • Corrosion Mitigation: Interlocking polyethylene barriers break the cathodic bond, preventing soil-to-tank electrolytic corrosion.
    • Durability: Breathable and virtually indestructible design that installs in minutes.
    • Integrated Manway: Features a precision-designed manway flat-spot, allowing the manway to hang over the edge for seamless installation and access.
    • Efficiency: Built-in forklift channels and reinforced handles make shipping, offloading, and site-positioning a breeze.
  • Customization & Orders
    • TuffBases are ready to ship and deliver nationwide by flatbed carrier. Check with a local authorized dealer or call us today for a quote. Custom strengths and colors are available upon request.

Installation Guide

Brochure Information

10’ Standard 10’ Heavy Duty
Kit Configuration (1) Universal Center, (3) 10’ Outers (1) HD Universal Center, (3) 10’ HD Outers
Kit Weight ~270 lbs. ~300 lbs.
Total Footprint 123″ Wide × 5″ Tall
Color Tan Natural
Max Recommended Weight 12 PSI (135,720 lbs.) 15 PSI (169,645 lbs.)
Max Operating Temp. 120°F (Sustained)
Material 100% LLDPE Polyethylene (Hard-Shell) with UV Stabilizer Additive

10’ Standard
Kit Configuration
(1) Universal Center, (3) 10’ Outers
Kit Weight
~270 lbs.
Total Footprint
123″ Wide × 5″ Tall
Color
Tan
Max Rec. Weight
12 PSI (135,720 lbs.)
Max Operating Temp.
120°F (Sustained)
Material
100% LLDPE Polyethylene (Hard-Shell) with UV Stabilizer Additive
10’ Heavy Duty
Kit Configuration
(1) HD Universal Center, (3) 10’ HD Outers
Kit Weight
~300 lbs.
Total Footprint
123″ Wide × 5″ Tall
Color
Natural
Max Rec. Weight
15 PSI (169,645 lbs.)
Max Operating Temp.
120°F (Sustained)
Material
100% LLDPE Polyethylene (Hard-Shell) with UV Stabilizer Additive

TuffBase

10'

CONTACT US TO LEARN MORE

Please call us at 405-542-3069, or submit your question using the contact form below.
